IBM-IMSourcing 32GB DDR3 SDRAM Memory Module

The new IBM 32 GB (1×32 GB, Quad-Rank x4, 1.35 V) PC3L-10600 CL9 ECC DDR3 1333 MHz VLP RDIMM for IBM BladeCenter HX5 is a low-cost way to add memory to IBM BladeCenter servers, and meet many of your memory-intensive workload requirements.

The 32 GB 1.35 V 4Rx4 RDIMM :

• Provides up to 1280 GB of DDR3 Memory on a 2-socket HX5 with MAX5 and up to 1024 GB per 4-socket HX5
• Is a Quad-rank RDIMM that helps maximize performance with the Intel Xeon E7-8800, E7-4800, and E7-2800 series processors of the HX5
• Is a 1.35 V low-voltage RDIMM that offers up to 20% energy savings over 1.5 V
• Supports running at both 1.35 V and 1.5 V

Product Type: RAM Module
Technical Information
Memory Size: 32 GB
Memory Technology: DDR3 SDRAM
Memory Voltage: 1.35 V
Number of Modules: 1 x 32GB
Memory Speed: 1333 MHz
Memory Standard: DDR3-1333/PC3-10600
Error Checking: ECC
Signal Processing: Registered
CAS Latency: CL9
Device Supported: Server
Physical Characteristics
Number of Pins: 240-pin
Form Factor: DIMM
Miscellaneous
Compatibility:

IBM Servers:

• BladeCenter HX5
• BladeCenter HX5 (7873)
• BladeCenter HS23 (7875)
• BladeCenter HS23
